Cho thuê lu rung bomag 213DH

Cho thuê lu rung bomag 213DH

  • Nhà sản xuất: bomag
  • Tình trạng: Còn hàng
Giá 40.000.000₫

Cho thuê lu rung bomag 213DH:

cho thuê lu rung bomagcho thuê lu rung bomagcho thuê lu rung bomagcho thuê lu rung bomag

Thông số kỹ thuật lu rung bomag 231DH:

Dimensions

A. OVERALL LENGTH 19.1 ft in 5808 mm
C. HEIGHT TO TOP OF CAB 9.8 ft in 2972 mm
D. WHEELBASE 9.7 ft in 2960 mm
E. GROUND CLEARANCE 19.3 in 490 mm
F. DRUM DIAMETER - FRONT 4.9 ft in 1500 mm

Specification

Engine
MAKE Deutz
MODEL BF4M1013EC
GROSS POWER 155 hp 115.6 kw
NET POWER 153 hp 114.1 kw
POWER MEASURED @ 2200 rpm
NUMBER OF CYLINDERS 4
Operational
OPERATING WEIGHT 27498 lb 12472.9 kg
FUEL CAPACITY 89.8 gal 340 L
MAX SPEED 8.7 mph 14 km/h
TIRES *IF APPLICABLE 23.1-26/12PR
OPERATING VOLTAGE 12 V
Drum
DRUM WIDTH 83.9 in 2130 mm
DRUM DIAMETER 59.1 in 1500 mm
STATIC LINEAR LOAD 191 lb/in 34.1 kg/cm
VIBRATION FREQUENCY 1 30 Hz
NOMINAL AMPLITUDE - MED 0.08 in 2 mm
CENTRIFUGAL FORCE - MED 67442.7 lb 300 kN
VIBRATION FREQUENCY 2 36 Hz
NOMINAL AMPLITUDE - MED 0.04 in 1 mm
CENTRIFUGAL FORCE - MED 50582 lb 225 kN
Dimensions
OVERALL LENGTH 19.1 ft in 5808 mm
HEIGHT TO TOP OF CAB 9.8 ft in 2972 mm
WHEELBASE 9.7 ft in 2960 mm
GROUND CLEARANCE 19.3 in 490 mm
DRUM DIAMETER - FRONT 4.9 ft in 1500 mm
